Features
- Economic solution for heavy duty application
- Heavy duty tube laser with side mounted chuck system and automated front loading system
- Max diameter up to 12.7 inches (optional 13.7 in) tube length up to 40 ft
- Two chuck system
TL-X Plus Series
TL-X Plus Series
Summary
Data
Information
| Technical Details | TL-X Plus | TL-X Plus II |
|---|---|---|
| Power | 3-12kW | 3-12kW |
| Rotating Speed of Chucks | 80r/min | 80r/min |
| Round Tube | 0.78-12.7 in | 0.78-13.7 in |
| Rectangle | 0.78*0.78-9*9in | 0.78*0.78 – 13.8*13.8 in |
| Single Tube Weight | 440lbs | 1102lbs |
| Tube Length | 6500-21ft
9000-30ft 12000-39ft |
6500-21ft
9000-30ft 12000-39ft |
