Features
- High Speed /High Power /High Performance in its class. Royce is designed to process the gauge sheet metal with ultra high productivity and cut thick Stainless / Aluminum plate with shiny clean cut edge.
- Maximum fiber laser power up to 20kW and beyond which enable to cut over 1” thick Stainless or Aluminum plate or cut mid-range thick plates with ultra-high speeds. For examples, 550ipm for 0.25” or 190ipm for 0.5” for Stainless.
- Royce is designed to be an open table structure which have two doors accessible to the cutting table, one from the front and one from the side. That way, the machine is much more easily accessible to the table for casual trouble-shooting and parts handling.
- Royce adopts the innovative and revolutionary flying-optics structure design to quantum-leap the speed and productivity of the system along with great gantry stability in high dynamics environment. Special gantry design and lower CGP (Center Gravity Point) are the keys for this innovative technology.
- Thanks to the above features, High JERK value is achieved for higher da/dt, as opposed to G value which is dv/dt. It rapidly accelerates acceleration instead of velocity.
- The fiber laser, electrical cabinet and gas control system are all built-in as part of one-body system so the time for installation and set-up is reduced, and the floor dimension is much more compact than the competitors.
- The new version HK HMI control application based on Siemens SINUMETIK 840D brings more user-friendly and innovative features to make the system even more competitive in terms of productivity, convenience and remote-monitoring.
- The high-speed and productivity the RS3015 provides is like no other machine we offer.
Layout
- The width of main body: RS 2190mm(86”) PS/FS 3300mm(130”) -> 34% compact
- The width of entire system: RS 3818mm(150”) PS/FS 5073mm(200”) -> 25% compact
- Total dimension required for installation: 20% compact, compared to PS/FS model
- Main body fits to 40’ container with side panels pre-assembled
- Electrical cabinet & laser built-in -> very easy to install & set up -> complete in a week
